Valves
>
Needle valve

Find the right needle valve for your requirements!

Our valve finder will help you find the right needle valve for your requirements. Searched and not found? Our range goes much further. For special products and individual advice, contact us directly.

Filter the results

Showing 43–48 of 160 results

    Channel penstock

    Type CC (Orbinox)
    Pressure: 1
    Nominal size: 150-2000

    “The Orbinox channel gate type CC is designed with a 3-sided sealing and for use in waste water technology, irrigation, hydropower utilisation and similar areas of application.

    The channel gate is a welded design in stainless steel (1.4301 / 1.4571) with a bolted-on elastomer seal.

    The model offers many design options for different dimensions and operating pressures.

    Actuator types: Manual operation, electric actuator, hydraulic actuator.”

    Add Bookmark

    Check valve

    Type ERK (ERHARD)
    Pressure: '10 / 16 / 25 / 40
    Nominal size: 150 - 1400
    ERHARD check valves are tried and tested double offset valves in a short weight-saving length. The freely oscillating valve disc has a flow-friendly design. The shaft bearings are designed to be maintenance-free and self-lubricating. Further advantages include the rolled up, solid housing seat ring and the disc seat ring with an elastic fine seal. These check valves are also available with a hydraulic damping device.
    Add Bookmark

    Compact ball valve, soft seated

    Type FA1 / FA2 / FB1 / FB2 / FC1 / FC2 (Adler)
    Pressure: 10 - 160 / 150 - 1500
    Nominal size: 10 - 250

    Due to its compact design, the compact Adler ball valve (Type FA1/FB1/FC1/FA2/FB2/FC2) is a space-saving variant of the flanged way ball valves.

    The valve is made of steel or stainless steel and can be produced as a wafer or flanged ball valve. Depending on the type, the valve is made of cast or solid material.

    The compact Adler ball valve is used in all industries.

    Add Bookmark

    Compact electric actuator with integrated control unit

    Type CM (Schiebel)

    “The Schiebel electric actuator series CM combines a compact and lightweight design with an integrated control unit.

    The built-in control unit can be extended simply and easily by means of software enablements.
    Due to the high power density of the motor, the CM series has very compact dimensions.
    In addition, these actuators have a lower weight due to the chosen material.

    Alternatively, it is possible to use special materials (e.g. bronze, steel).

    Due to its high protection class, the electric actuator CM can be used virtually anywhere.”

    Add Bookmark

    Control valve

    Type RV (ERHARD)
    Pressure: '16 / 25 / 40
    Nominal size: 50 - 150
    ERHARD control valves type RV are designed for throttling and regulation in water treatment and water distribution plants as well as in hydropower plants. The slotted bush also provides optimum flow behaviour for harmless energy conversion. The control valve is ideally suited for continuous operation during cavitation. The ERHARD control valve is available with a handwheel, electric actuator, hydraulic or pneumatic piston actuator. A straight or angle version is possible.
    Add Bookmark

    Cryogenic and high temperature control valve

    Type RC260 (USA: Typ 884) (Badger Meter)
    Pressure: max.172 bar
    Nominal size: 1/4", 1/2", 3/4", 1"

    The Badger Meter cryogenic control valve has been specially developed for media with t<-50°C.

    It controls liquids, gases or steam in general industry, research, development and pilot plants.

    The bellows design must be used for the inner valves.

    Add Bookmark
