Find the right needle valve for your requirements!
Our valve finder will help you find the right needle valve for your requirements. Searched and not found? Our range goes much further. For special products and individual advice, contact us directly.
Filter the results
Showing 85–90 of 160 results
High pressure control valve
Type HP-10 (10000psi) (Badger Meter)
Pressure: max. 689 bar
Nominal size: 1/4", 1/2"
The high-pressure control valve type HP-10 is used wherever the standard type RC200 comes to its limits due to too high pressure.
The high-pressure control valve type HP-10 is the right valve for liquids and gases in high-pressure applications with medium to small flow rates and is available as a globe or angle valve.
LDM Valves, 2- und 3-Wege Regelventile
(LDM Valves)
Pressure: PN16-PN40
Nominal size: DN15-300
"Straight and 3-way type control valve with a mixing or distribution function.
Housing material: Spheroidal cast iron, cast steel, stainless steel.
Turndown ratio: 50:1
Optionally with bellows, LDM spline, perforated cone,
Oxygen and food-compatible design available
Nominal diameters: from DN15 - DN300, PN16 - PN40
Temperatures: from -20°C to +500°C
Leakage rate class: III/IV according to EN1349
Length according to EN 558-1
Approvals: CE, ATEX, ISO9001:215, TRD100/110/201, TRB 801, ISO14001:2015, OHSAS"
Limit switch box
Type i-box (Eurotec)
Compact, simple and efficient.
The i-box is produced by the quality manufacturer Eurotec in Germany. Thanks to its sophisticated mounting system, it can be quickly and easily installed directly on the actuator and is therefore extremely space-saving. Despite its very compact design, it offers space for 1 to 2 mechanical toggle switches or inductive sensors in the V3 design.
Its large OPEN-CLOSED display is still visible even from a distance. Alternatively, it can be equipped to display T or L-bores. The standard version is suitable for an 80x30 mm actuator bore pattern with shaft heights of 20 and 30 mm. The height and width adjustable stainless steel bracket IMBHV is required for other bore patterns. The i-box housing achieves protection classes IP66 and IP67 according to DIN EN 60529.
Limit switch box
Type wave (Eurotec)
"The all-rounder: flexible, compact and easy to stock.
The wave limit switch box was developed in 2008 and is still produced exclusively in Germany today.
The Eurotec wave is very flexible with its classic design. It accommodates 1-4 mechanical microswitches and sensors in the V3 design. Slot initiators and cylindrical sensors (max. diameter 18 mm / max. length 50 mm) can also be installed.
The housing is available in polyamide, Vestamid and aluminium. All versions of the wave series achieve protection class IP67 due to the curved bonnet.
There is a low-cost version with a very stable glass fibre-reinforced plastic bracket and a chemical version with our high-quality stainless steel bracket MBHV.
All brackets are height and width adjustable and are included as standard."
Limit switch box
Type d-Box, neptun, flex (Eurotec)
In addition to our Eurotec main products, the wave and i-Box, we also have all the other Eurotec limit switch boxes in our range.
flex Box: Nomen est omen - this model is particularly flexible and is suitable for harsh conditions with particular requirements for stability and load capacity as well as for applications with a salty atmosphere, sulfur gases and ammonia nitrate.
neptun: made of high-quality stainless steel, it is particularly resistant to corrosion and pitting. For use in offshore applications, the chemical industry and environments with a salty atmosphere, sulfur gases, ammonia nitrate and numerous other aggressive media.
big Box: For large cylindrical sensors with an M30 thread or special length.
Eurobox: For larger and above all longer sensors.
These include the d-Box, the neptun, the Eurobox, the flex model as well as the big box or the plastic version.
Please visit the manufacturer's website or contact one of our team for more information on these products.
Low noise ball segment valve
Type Typ KVTW LN / KVXW LN / KVTF LN / KVXF LN (Somas)
Pressure: 50
Nominal size: 50-400
Somas ball segment valves type KVTW LN (KVTF LN) with a centrically mounted shaft and KVXW LN (KVXF LN) with an eccentrically mounted shaft were developed to reduce noise levels.
The reduction in the noise level is achieved by the installation of a noise-reducing device. The noise-reducing device is mounted behind the ball segment and consists of several steel rods in a specific arrangement. These steel rods distribute the pressure drop over several stages. This reduces the noise level and prevents any cavitation.
The KVTW LN and KVXW LN are supplied as wafer type valves and the KVTF LN and KVXF LN as flange type valves.
