Additional information
| Marken | Orbinox |
|---|---|
| Funktion | Control valves, On-off valves |
| Industrie | Water, waste water |
| Anwendung | Water & waste water |
| Nenndruck | Special pressure |
| Betriebstemperatur | Standard temperature |
Wall mounted penstock
Related products
Wafer style knife gate valve for reject and discharge applications
Type CR (Orbinox)
Pressure: 7
Nominal size: 100-600
“The model CR from Orbinox is a wafer valve designed for problematic applications.
The two-piece housing with a round inlet and square outlet, which is larger than the inlet, avoids blockages.
The wafer valve is generally used for recycling applications, such as junk or sand traps on pulpers, high density cleaners, screening or as a silo outlet with solid material.
“
Double gate knife gate valve
Type DT (Orbinox)
Pressure: 10
Nominal size: 100-600
“The knife gate valve type DT from Orbinox is a bi-directional gate valve that is mainly used for higher consistencies in the pulp and paper industry (paper recycling), but is particularly used for heavily contaminated fibrous media.
Closing and opening times are only half as long as with other gate valves.
All parts that are subject to wear can be easily replaced.”
Through conduit bi-directional high pressure knife gate valve
Type TH (Orbinox)
Pressure: 10
Nominal size: 300-1000
“The model TH from Orbinox is a bi-directional high pressure through conduit wafer valve. The knife gate valve is designed for media with a high consistency and can be used for consistencies up to 12%.
The valve can be used in a wide range of industrial sectors.
The bi-directional sealing principle ensures blockage-free shut-off in both flow directions.
All versions have a two-piece housing with internal sliding bars to ensure smooth operation.
The cast sealing ring system (type K) improves the tightness and makes it easier to change seals. “
Square port knife gate valve for solid loaded fluids
Type BC (Orbinox)
Pressure: 1
Nominal size: 150-600
The knife gate valve type BC from Orbinox is a square or rectangular port low-pressure knife gate valve in welded design for liquids containing solids and solids and is mainly used in bulk handling and silo outlet applications. It is generally used for media such as liquids with solids, granulate, powders and other materials.
